WateRRake Model FS is the answer for most screening applications. With the simple and rugged designed,   WateRRake makes installation and maintenance easy.   The unit consists of all steel epoxy coated or stainless steels construction, and can be set into a straight channel requiring no knockouts or floor depression.   It is greatly suitable for removing suspended and floating coarse and fine debris such as floating plants, weeds, and plastic from surface water.

No Shear Effects
All type of bar screen and wedged wire have fixed bar and rotating blade or scraper.   The relative movement between the fixed and the moving shear the trashes into smaller pieces.  The concept of Model FS is to lift the trashes up without shearing forces that would cut the trashes. With Model FS, lump fragile solids will not be broken and jammed between the bar spacing.

Self Cleaning Movement
Every fine screening catches solids between their bar, grid, or elements; but they differ in how the solids are rejected from the bar. Simply gravity or spraying are inadequate.   The self-retracting path movement of Model FS provides self-cleaning action other types of screen can not do.   When selecting a fine screen, make sure that you pay most attention in how the screen cleans itself.

High Capacity Low Headloss
The filter element can scoop large and heavy debris with its hooked shaped element.   With the lagging element of the front arm and rear arm, a smaller passage for solids occurred while giving higher surface area for water passage.

Easy Installation and Maintenance
Model FS is made completed at factory.   Installation is just a matter of lift, place and a couple of bolt tightening.   All maintenance can be done at floor level.   There is no immersed bearings or rotating parts.
